Dimensions without packing: • Height : 60.4"
• Width : 15.8"
• Depth : 22.3"
• Weight with SCDU : 220.2 lbs
Dimensions with packing: • Height : 73.1"
• Width : 18.7"
• Depth : 26.7"
• Weight with SCDU : 245.2 lbs
Power Requirements: • 110/220 VAC ±10%, 50/60 Hz, 145 Watts
Temperature Requirements: • In storage: 32°F - 104°F (0°C ~ 49°C)
• While operating: 45°F - 95°F (5°C ~ 35°C)
Allowable Humidity: • In storage : 10% < RH < 90%, non-condensed
• While operating : 15% < RH < 85%, non-condensed

Monitor: • High-Res 17" touch screen LCD panel
• LED Back-light
• 1920 x 1080 full resolution
• 1024 x 768 for video advertising
Printer: • 80mm Thermal Receipt Printer
• 40 Characters per line
• 200 DPI mono-graphic printing
PIN Entry Device: • 16-key alphanumeric keypad
• PCI Certified
• Triple-DES (TDES) compliant EPP
Cash Dispenser: • Up to 4 x 2000 Notes Removable Cassette
CPU: • Coretex-A9 Dual Core
• DDR3 1Gbytes
• 512MBytes NAND Memory
• Windows CE 7.0
Card Reader: • EMV (Dip type)
ADA: • Voice Guidance
• Lighted Transaction Guidance
• Accessible Keypad Layout
Security: • UL291 Business Hours Vault
• Electronic lock
• Kaba Mas Cencon Series Lock
• Level 1 Vault (Optional)
Communication: • TCP/IP Ethernet connection - Onboard SSL
