Dimensions without packing: • Height : 56.8"
• Width : 24"
• Depth : 35.5"
• Weight with 2H PCDU : 340 lbs
Dimensions with packing: • Height : 65.2"
• Width : 26.1"
• Depth : 37.8"
• Weight with 2H PCDU : 389.4 lbs
Power Requirements: • 110/220 VAC ±10%, 50/60 Hz, 145 Watts
Operating Environment: • Temperature range : 40°F - 95°F
• Relative humidity : Non-condensing = 15% - 85%

Integrated Illuminated Topper Sign: • High Visibility LED Sign
• Attract Customers
LCD Screen: • 15 inch color TFT-LCD Panel
• High bright LED backlight (800 cd/m2)
• 1024x768 (XGA) Resolution
Printer: • 80mm / 3" Receipt Printer
• 200 DPI monographic printing
PIN Entry Device: • 16-key alpha numeric keypad
• PCI/Interac Certified
• Triple-DES (TDES) EPP
Rear Service Panel: • 7 inch color touch screen
• Backlit TFT LCD Panel
• 800x480 Resolution
Communication: • 56Kb Internal Model
• TCP/IP Ethernet - SSL
CPU: • Coretex-A9 Dual Core
• DDR3 1Gbytes
• 512MBytes NAND Memory
• Windows CE 7.0
Card Reader: • DIP Style Magnetic Card Reader
• EMV - Optional
ADA: • Voice Guidance
• Lighted Transaction Guidance
• Accessible Keypad Layout
Security: • UL291 Business Hours Vault
• Electronic Lock or Cencon (optional)
Cash Dispenser: • Up to 3 x 2000 Note Removable Cassette
