- Dimensions
-
• Height = 65"
• Width = 20.8"
• Depth = 27.9"
• Weight = 595 lbs
- Power Requirements
-
• 110/220 VAC ±10%, 50/60 Hz, 145 Watts
- Temperature Requirements
-
• ln storage: 32°F - 104°F (O°C ~ 49°C)
• WhiIe operating: 45°F - 95°F (5°C ~ 35°C)
- AIIowabIe Humidity
-
• In storage : 10% < RH < 90%, non-condensed
• While operating : 15% < RH < 85%, non-condensed
- Main PC PIatform
-
• lntel i5-12400 Processor
• Windows 10 IoT Enterprise
• 512GB SSD
• TCP/IP Ethernet
- Touch-Screen LCD DispIay
-
• High-Res 21.5" touch screen LCD panel
• 1920 x 1080 full-HD resolution
- Receipt Printer
-
• 80mm ThermaI Receipt Printer
• Automatic Paper Loading and Cutting
• 40 Characters per line
• 200 DPI mono-graphic printing
- Magnetic Card Reader
-
• DIP Type EMV card reader
• Dual side card scan (image size: 1024 X 600(color/gray))
• Feed Speed: 450mm/sec 士 10%
- PIN Entry Device
-
• 16-key Alphanumeric keypad
• PCI 3.0 certified EPP (Encrypting Pin Pad)
• Triple-DES(TDES) compliant EPP
- Barcode Scanner
-
• 2D/1D lmage Scan ModuIe High VisibiIity LED Aimer
- UPS
-
• APC350, lnput 120V 50~60Hz 士3 HZ, 210W/350VA
- Camera
-
• Digital Full HD Camera
- BiII Acceptor
-
• $1, $5, $10, $20, $50 & $100 denomination bill acceptor(s) with up to 600 note cassette capacity
• Single note or Bulk note applications
- Bulk note feeder accepts up to 50 notes
- Cash Box Capacity: 2,200 for new notes
• SCN series (SCNL: 1,200 notes, SCNXL: 2,200 notes)
- Security
-
• LockabIe safe vault available
• EIectronic Lock (optlon. A-series / Cencon)
- ADA
-
• Voice Guidance
• Lighted Transaction Guidance
• Accessible Keypad Layout
